The 80+BRONZE certified Performance A+ III series, using the high standard of DC/DC technology, supplies increased efficiency and maximum electrical stability even during excessive gaming. This individual use of the cables supports an optimized air flow for each computer case and improve heat dissipation. Six integrated safety circuits provide an all-time safe operation and the sleeved main cable harness ensures order in the PC case.
450W | 80+ Bronze
XN081 | XP450R11550W | 80+ Bronze | semi-modular
XN083 | XP550MR11650W | 80+ Bronze
XN084 | XP650R11650W | 80+ Bronze | semi-modular
XN085 | XP650MR11750W | 80+ Bronze | semi-modular
XN087 | XP750MR11850W | 80+ Bronze |semi-modular
XN089 | XP850MR11Rendimiento contínuo (W) | 550 |
Factor de forma ATX 12V | Version 2.52 |
Tensión de red (Vac) | 200 - 240 |
Modelo | Performance A III | XP550R11 |
Frequencia de la red (Hz) | 50 - 60 |
Corriente nominal (A) | 6.3 |
PFC | active |
+3.3V (A) | 20 |
+5V (A) | 20 |
+12V1 (A) | 45.8 |
-12V (A) | 0.3 |
+5Vsb (A) | 3.0 |
Rendimiento total max. 12V (W) | 550 |
Rendimiento total max. 3,3V + 5V (W) | 100 |
+12V2 (A) | - |
Tecnología de rodamiento | FDB |
Tamaño del ventilador (mm) | 120 |
OCP (protección de sobrecorriente) | ✓ |
OVP (protección de sobretensión) | ✓ |
UVP (protección de mínima tensión) | ✓ |
SCP (protección contra cortocircuito) | ✓ |
OTP (protección de sobrecalentamiento) | ✓ |
OPP (protección de sobrecarga) | ✓ |
Certificación 80PLUS | Bronze |
eficiencia (%) a 230V, carga 20% | 85 |
Effizienz (%) a 230V, carga 50% | 88 |
Effizienz (%) a 230V, carga 100% | 85 |
ErP | ✓ |
WEEE | ✓ |
RoHS | ✓ |
Gestión de cables modular | - |
Longitud de cable a la placa base (mm) | 550 |
Longitud del cable hasta el 1.er conector (mm) | 450 |
Longitud de cable máxima(mm) | 750 |
Cables encamisados | - |
Número de cables | 6 |
Placa madre ATX (20+4-pin) | 1 |
P4+4 (CPU) | 1 |
P8 (CPU) | - |
PCI-E 6-pin (GPU) | - |
PCI-E 6+2-pin (GPU) | 2 |
PATA 4-pin | 3 |
SATA 15-pin(HDD, unidades) | 6 |
FDD (Floppy) | - |
Serie de productos | Performance A III |
Número de artículo | XN082 |
Código EAN | 4044953502507 |
Dimensiones, Embalaje (L x An x Al), (mm) | - |
Peso bruto, por unidad (kg) | - |
Número por unidad de embalaje (UE) | - |
Dimensione UE (L x An x Al), (mm) | - |
Peso bruto UE (kg) | - |
